LT599-Artery Wire spiral hydraulic hose
Application： Suitable for using oil base hydraulic oil, is suitable for the harsh conditions of high temperature and medium pressure hose
Tube：Inner tube of NBR tube
Reinforcement：4 layers or 6 layers of interlaced high-strength steel wire
Cover： Narrow cloth black non-stripping outer rubber
Standard：ISO18752-DC standard
Temperature range：-40℃~+121℃ (-40℉~+250℉)
Paramter
|
SIZE (Dash) |
SIZE |
I.D. |
O.D. |
Max.W.P. |
Min.B.P. |
Min.B.R. |
|
|
Min |
Max |
Max |
(MPa) |
(MPa) |
(mm) |
||
|
6 |
1/4-4S |
6.0 |
6.8 |
18.7 |
70 |
280 |
120 |
|
10 |
3/8-4S |
9.3 |
10.1 |
22.2 |
56 |
224 |
150 |
|
13 |
1/2-4S |
12.8 |
13.5 |
25.0 |
42 |
168 |
190 |
|
16 |
5/8-4S |
15.9 |
16.6 |
28.4 |
42 |
168 |
200 |
|
19 |
3/4-4S |
18.8 |
19.6 |
32.3 |
42 |
168 |
224 |
|
25 |
1-4S |
25.0 |
25.8 |
39.3 |
42 |
168 |
272 |
|
32 |
1-1/4-4S |
31.6 |
32.6 |
46.0 |
35 |
140 |
370 |
|
32 |
1-1/2-4S |
37.8 |
38.8 |
53.4 |
29 |
116 |
540 |
|
38 |
2-4S |
50.7 |
52 |
68.5 |
25 |
100 |
660 |
|
51 |
1 1/4-6S |
31.6 |
32.6 |
50.8 |
42 |
168 |
420 |
|
51 |
1 1/2-6S |
37.7 |
38.8 |
57.3 |
42 |
168 |
500 |
|
51 |
2-6S |
51.6 |
51.8 |
71.5 |
42 |
168 |
650 |
